A range of 10x38mm fuse links specifically designed for protecting photovoltaic strings. These fuse links are capable of interrupting low overcurrents associated with faulted photovoltaic string arrays
(reverse current, multi-array fault)
Structural Characteristics
□ According to IEC60269-1
□ Rated current: 1-32A
□ Rated voltage: DC 1000V
□ Rated breaking capacity:DC 33kA
□ Operating class gPV for Solar protection
Specification
Pole 1P
Rated Voltage Ue (V DC) 1000
Rated Current In (A) 1, 2, 3, 4, 5, 6, 8, 10, 12,15, 20, 25, 32
Biggest Block Ability(KA) 33
The Most High Power Consumption(W) 3.5
